వర్ణద్రవ్యం వైలెట్ 23-కోరిమాక్స్ వైలెట్ RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

వర్ణద్రవ్యం వైలెట్ యొక్క సాంకేతిక పారామితులు 23

రంగు సూచిక సంఖ్య.వర్ణద్రవ్యం వైలెట్ 23
ఉత్పత్తి నామంకోరిమాక్స్ వైలెట్ RLS
ఉత్పత్తి వర్గంసేంద్రీయ వర్ణద్రవ్యం
తేలికపాటి ఫాస్ట్నెస్ (పూత)7
వేడి నిరోధకత (పూత)200
తేలికపాటి ఫాస్ట్నెస్ (ప్లాస్టిక్)7
వేడి నిరోధకత (ప్లాస్టిక్)250
రంగు
వర్ణక-వైలెట్-23-రంగు
రంగు పంపిణీpv

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

లక్షణాలు:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

అప్లికేషన్:

ఆటోమోటివ్ పెయింట్స్, ఆర్కిటెక్చరల్ పూతలు, కాయిల్ పూతలు, ఇండస్ట్రియల్ పెయింట్స్, పౌడర్ కోటింగ్స్, ప్రింటింగ్ పేస్ట్స్, పివిసి, రబ్బరు, పిఎస్, పిపి, పిఇ, పియు, ఆఫ్‌సెట్ ఇంక్‌లు, నీటి ఆధారిత ఇంక్‌లు, ద్రావణి ఇంక్‌లు, యువి ఇంక్‌లు కోసం సిఫార్సు చేయబడింది.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
-------------------------------------------------- ---------------

సంబంధించిన సమాచారం

భౌతిక మరియు రసాయన గుణములు:
రంగు లేదా కాంతి: నీలం ple దా
సాపేక్ష సాంద్రత: 1.40-1.60
బల్క్ డెన్సిటీ / (ఎల్బి / గాల్): 11.7-13.3
ద్రవీభవన స్థానం / ℃: 430-455
సగటు కణ పరిమాణం / μm: 0.04-0.07
కణ ఆకారం: క్యూబిక్ / రాడ్
నిర్దిష్ట ఉపరితల వైశాల్యం / (m2 / g): 45-102
pH విలువ / (10% ముద్ద): 6.2

ఉత్పత్తి ఉపయోగం:పిగ్మెంట్ వైలెట్ 23 ప్రధానంగా పూతలు, సిరాలు, రబ్బర్లు మరియు ప్లాస్టిక్‌ల రంగు కోసం మరియు సింథటిక్ ఫైబర్స్ యొక్క రంగు కోసం ఉపయోగిస్తారు
వర్ణద్రవ్యం యొక్క 124 రకాల వాణిజ్య సూత్రీకరణ బ్రాండ్లు ఉన్నాయి. కార్బాజోజైన్ అనేది ఒక రకమైన నీలం వైలెట్ రకం, ఇది బలమైన మరియు అసాధారణమైన అనువర్తనంతో ఉంటుంది, మరియు మోనోలైట్ వైలెట్ RN యొక్క నిర్దిష్ట ఉపరితల వైశాల్యం 74 మీ 2 / గ్రా. పూత, ఇంక్ ప్రింటింగ్, ప్లాస్టిక్ మరియు ఫాబ్రిక్ ప్రింటింగ్ మరియు డైయింగ్ వంటి వివిధ రంగాలలో ఇది విస్తృతంగా ఉపయోగించబడుతుంది. రంగు వేసేటప్పుడు వార్నిష్ చేయడానికి మంచి ఫాస్ట్‌నెస్ ఉంటుంది. ఇది ఎయిర్ ఎండబెట్టడం పెయింట్, ఆటోమొబైల్ పెయింట్ OEM మరియు బేకింగ్ పెయింట్ కోసం ఉపయోగించవచ్చు, ముఖ్యంగా CuPc టోనర్ మరియు బలమైన లైట్ టోన్‌తో రబ్బరు పెయింట్ కోసం. ప్లాస్టిక్ కలరింగ్ కోసం దీనిని ఉపయోగించవచ్చు, పాలియోలిఫిన్లో 280 heat యొక్క వేడి నిరోధకత మరియు అధిక రంగు నిలుపుదల (1/3SD తో HDPE కి 0.07% వర్ణద్రవ్యం ఏకాగ్రత మాత్రమే అవసరం); ఇది పాలిస్టర్ మరియు PE యొక్క రంగు కోసం కూడా ఉపయోగించవచ్చు.

సంశ్లేషణ సూత్రం: కార్బజోల్ ఒక ముడి పదార్థంగా ఉపయోగించబడుతుంది, మరియు ఒక దశ విలోమ ఉత్ప్రేరకం సమక్షంలో సాధారణ ఒత్తిడిలో N- ఇథైలేషన్ నిర్వహిస్తారు మరియు 2-అమైనో-ఎన్-ఇథైల్కార్బజోల్‌ను సంశ్లేషణ చేయడానికి నైట్రేషన్ ప్రతిచర్య మరియు తగ్గింపు ప్రతిచర్య నిర్వహిస్తారు; 3,5,6-టెట్రాక్లోరోపరాక్వినోన్ (క్లోరనిల్) సంగ్రహణ మరియు రింగ్-మూసివేత ప్రతిచర్యలకు లోబడి, ఫిల్టర్ చేయబడి, నీటితో కడిగి, ముడి కార్బజోల్ వైలెట్ పొందటానికి ఎండబెట్టి; చివరగా, CI పిగ్మెంట్ వైలెట్ 23 ను పొందటానికి కండరముల పిసుకుట / పిసికి కలుపుట ద్వారా సాధారణ పిగ్మెంటేషన్ చికిత్స.

మారుపేర్ల:Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

పరమాణు నిర్మాణం:వర్ణక-వైలెట్-23 పరమాణు నిర్మాణం
